Máy chủ tọa TOA TS-811

Mã số:23020408

Máy chủ tọa TOA TS-811

The TS-811 is a Chairman unit that can be connected to the conference system by a cable. It is equipped with a priority switch, allowing speech to take precedence over the Delegate unit. The TS-811 is directly connected to the TS-919B1 or TS-919B4 Bridge unit, then to the TS-910 Central unit via the TS-918 Expansion unit. Either the standard type or long type can be selected for the microphone.

Specifications

Model TS-811

Power Source 24 VDC (supplied from the TS-918 Expansion Unit (option))

Current Consumption Max. 60 mA

Modulation Method Frequency modulation

Carrier Frequency Transmission: Audio channel 1: 7.35 MHz Audio channel 2: 8.10 MHz Audio channel 3: 8.55 MHz Audio channel 4: 9.15 MHz Control channel: 6.45 MHz Reception: Audio channel: 1.95 MHz

Input Microphone terminal: XLR-4-3 type

Output Monitor speaker: 8 Ω, 0.2 W Headphone: φ3.5 mm mini Jack (3P: monaural) × 2

Connection Terminal RJ45 connector

Function Monitor volume control, Headphone volume control, Priority speech function

Finish Top panel: ABS resin, gray metallic, paint, semi-gloss

Dimensions 210 (W) × 68.6 (H) × 152 (D) mm

Weight 560g

• Sản xuất tại Việt Nam.
