Mainboard Asus Z97-PRO GAMER

Dòng sản phẩm Mainboard Asus Z97 - Deluxe

Bộ xử lý Intel Core i3/i5/i7 Processors/Celeron Processors/Pentium Processors Support Intel 22nm CPU Support Intel Turbo Boots Technology 2.0

Socket LGA1150

Chipset Intel Z97

Bộ nhớ 4 x DDR3 DIMM Slots Dual channel DDR3 1333/1600/.../3300 MHz, up to 32GB Support for Extreme Memory Proflie (XMP)

Đồ họa 1 x DisplayPort (4096 x 2160) 1 x Mini DisplayPort (4096 x 2160) 1 x HDMI port (4096 x 2160) Maximum shared memory of 512 MB Support up to 3 displays simultaneously

Network 1 x Gigabit LAN Controller

Khe cắm mở rộng 2 x PCIe 2.0 x 16 slots (x 16 mode) 2 x PCIe 3.0 x 16 slots (x 8 mode) 1 x PCIe 3.0 x 16 slots (x 4 mode) 4 x PCIe 2.0 x 1 slots

Cổng HDD 4 x SATA 6.0 Gb/s port (Gray) 1 x M.2 Socket 3 1 x SATA Express port

Cổng USB Intel Z97 Chipset:8 x USB 2.0 port (4 port on the back panel, 4 port on mid-board)4 x USB 3.0 port (4 port on the back panel)ASMedia USB 3.0 Controller:6 x USB port (2 port on the back panel, 4 port on mid-board)

Cổng PS/2 1 x PS/2 Mouse port (Green) 1 x PS/2 Keyboard port (Purple)

Cổng Audio Realtek ALC1150 8 channelHigh Definition Audio
