Mainboard Asrock X470 Taichi

• Hỗ trợ CPU AMD AM4 Socket Ryzen Series (Summit Ridge, Raven Ridge và Pinnacle Ridge)

• Hỗ trợ DDR4 3466+ (OC)

• 2 PCIe 3.0 x16, 1 PCIe 2.0 x16, 2 PCIe 2.0 x1

• Quad SLI của NVIDIA®, AMD Quad CrossFireX ™

• Âm thanh HD 7.1 CH (Realtek ALC1220 Audio Codec), Hỗ trợ Tín hiệu âm thanh 4 và DTS Kết nối

• 8 SATA3, 1 Ultra M2 (PCIe Gen3 x4 và SATA3), 1 M.2 (PCIe Gen2 x4 và SATA3)

• 3 USB 3.1 Gen2 (Loại phía sau A + C, Loại Front C), 10 USB 3.1 Gen1 (4 Mặt trước, 6 Bên sau)

• Intel® Gigabit LAN, Intel® 802.11ac + BT 4.2

• ASRock Polychrome RGB

THÔNG SỐ CHI TIẾT

Sản phẩm Bo mạch chủ

Tên Hãng Asrock

Model X470 Taichi

CPU hỗ trợ AMD

Chipset X470

RAM hỗ trợ 4 x DDR4 DIMM Slots support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 ECC & non-ECC, un-buffered

Khe cắm mở rộng

AMD Ryzen series CPUs (Summit Ridge and Pinnacle Ridge) - 2 x PCI Express 3.0 x16 Slots (single at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE3))*

AMD Ryzen series CPUs (Raven Ridge) - 1 x PCI Express 3.0 x16 Slot (single at x8 (PCIE1))*

• 1 x PCI Express 2.0 x16 Slot (PCIE5 @ x4 mode)**
• 2 x PCI Express 2.0 x1 Slots (Flexible PCIe)
• Supports AMD Quad CrossFireX™ and CrossFireX™***
• Supports NVIDIA® Quad SLI™ and SLI™***
• 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ac module (on the rear I/O)
• 15μ Gold Contact in VGA PCIe Slot (PCIE1 and PCIE3)

Ổ cứng hỗ trợ

• 6 x SATA3 6.0 Gb/s

• 1 x Ultra M.2 Socket (M2_1), supports M Key type 2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express

• 1 x M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280 M.2 PCI Express

Cổng kết nối (Internal) - 1 x Power LED and Speaker Header - 1 x AMD Fan LED Header - 1 x RGB LED Header - 1 x Addressable LED Header - 1 x CPU Fan Connector (4-pin) - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) - 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)** - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) - 1 x 4 pin 12V Power Connector (Hi-Density Power Connector) - 1 x Front Panel Audio Connector (15μ Gold Audio Connector) - 1 x AMD LED Fan USB Header - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) - 2 x USB 3.1 Gen1 Headers (Support 4 USB 3.1 Gen1 ports) (Supports ESD Protection) - 1 x Front Panel Type C USB 3.1 Gen2 Header (ASMedia ASM3142) - 1 x Dr. Debug with L
